Descriptio Producti
| Inlet temperatus | ≤50 ℃ |
| Refrigerium | Aeris-REFRIGENS |
| INLETUM | 0,6 ~ 1.0MPA |
| Pressura gutta | ≤0.02mpa |
| CORPUS | II ~ X ℃ |
| Refrigerant | Environmentally amica refrigerare r410a, r407c |
| Ambientium temperatus | ≤38 ℃ |
| Exemplar | Dm007nf | Dm015nf | Dm026nf | Dm040nnf | Dm065nf | Dm085nf | Dm110nf | Dm138nf | Dm150nf | Dm200nf | Dm250nf | Dm300nf | Dm400nf | Dm500nf | ||
| Capacitatem (NM 3 / Min) | 0.7 | 1.5 | 2.6 | 4 | 6.5 | 8.5 | 11 | 13.8 | 17 | 23 | 27 | 35 | 45 | 55 | ||
| Voltage (V / HZ) | 220/50 | 380/50 | 380/50 | |||||||||||||
| Compressor Power (HP) | 0.85 | 1 | 1 | 1.25 | 1.5 | 2 | 3 | 3.5 | 4 | 5 | 6 | 8 | 10 | 12 | ||
| Air | RP1 | RP1.5 | RP2 | Dn65 | Dn80 | Dn100 | Dn125 | |||||||||
| Pondus (kg) | 50 | 58 | 75 | 95 | 115 | 130 | 165 | 215 | 265 | 320 | 360 | 420 | 580 | 678 | ||
| Dimensiones (mm) | Longitudo | 630 | 650 | 750 | 800 | 950 | 1050 | 1180 | 1180 | 1240 | 1420 | 1650 | 1650 | 1850 | 1980 | |
| Latitudo | 375 | 400 | 450 | 450 | 500 | 500 | 630 | 670 | 670 | 790 | 820 | 820 | 920 | 930 | ||
| Altitudo | 670 | 690 | 730 | 800 | 880 | 950 | 1050 | 1050 | 1188 | 1340 | 1370 | 1370 | 1500 | 1800 | ||
| Exemplar | Dm150nw | Dm200nw | Dm250nw | Dm300nw | Dm400nw | Dm500nw | Dm600nw | Dm800nw | Dm1000nw | Dm1200nw | Dm1500nw | Dm1800nw | Dm2000nw | Dm3000nw | Dm4000nw | |
| Capacitatem (NM 3 / Min) | 17 | 23 | 27 | 35 | 45 | 55 | 65 | 85 | 100 | 120 | 150 | 180 | 200 | 300 | 400 | |
| Voltage (V / HZ) | 380/50 | |||||||||||||||
| Compressor Power (HP) | 4 | 5 | 6 | 8 | 10 | 12 | 15 | 20 | 25 | 30 | 37 | 45 | 50 | 80 | 100 | |
| NM 3 / Min | 3 | 3.7 | 4.4 | 6 | 7.4 | 8.9 | 11.1 | 12.4 | 14.5 | 16.5 | 18.5 | 21.5 | 24.5 | 36 | 48 | |
| Air | Dn65 | Dn80 | Dn100 | Dn125 | DN150 | Dn200 | Dn250 | Dn300 | ||||||||
| AQUA | Rp1 | RP11 / II | RP2 | RP21 / II | Dn80 | Dn100 | ||||||||||
| Pondus (kg) | 300 | 385 | 500 | 595 | 660 | 710 | 943 | 1450 | 2150 | 2360 | 2550 | 3000 | 3200 | 3860 | 4200 | |
| Dimensiones (mm) | Longitudo | 1240 | 1420 | 1650 | 1650 | 1850 | 1980 | 2080 | 2200 | 2450 | 2450 | 2650 | 2720 | 3450 | 3800 | 4200 |
| Latitudo | 670 | 790 | 820 | 820 | 920 | 920 | 930 | 1250 | 1350 | 1440 | 1550 | 1650 | 1725 | 1980 | 2150 | |
| Height | 1180 | 1338 | 1370 | 1410 | 1550 | 1670 | 1834 | 1850 | 1850 | 1900 | 2193 | 2260 | 2380 | 2580 | 2670 | |
